Hydraulic fork positioner is a device that helps adjust the distance between two forks without having to get off the vehicle to do it manually. This is an important accessory that helps the forklift increase working efficiency , reduce operating time and improve safety during operation.
Technical specifications hydraulic fork positioner 3-3.5 ton capacity
| Capacity | Load Center |
Model | Opening Range |
Min. Truck Carriage Width |
Carriage Width |
Fork Width |
Weight |
| O | W | S | |||||
| kg | mm | mm | mm | mm | mm | kg | |
| 3000 | 600 | FPS30K-1100B | 305-975 | 935 | 1100 | 122 | 290 |
| 3000 | 500 | FPS30G-1100B | 285-1015 | 935 | 1100 | 125 | 86 |
Advantages:
1. Fork positioner allows the operator hydraulically move the forks closer together or further apart, individually or together.
2. It is particularly useful when the operator has to handle a variety of pallet sizes.
3. The operator doesn’t need to manually adjust the forks, thus saving time.
1, Basic Technical Specifications
Support load : 3 – 3.5 tons
Fork adjustment range : 200mm – 1600mm (depending on type)
Required hydraulic pressure : 140 – 200 bar
Equipment weight : 150 – 250kg
Fork type : Standard or customized according to needs
Hydraulic port requirement : Add 1 set of oil lines (if the forklift is not available)
2, Benefits of Using Fork Positioner
Faster fork spacing adjustment : Reduces manual operation time.
Increased flexibility : Suitable for many types of pallets and goods of different sizes.
Improved safety : Reduces the risk of accidents when having to adjust the forks manually.
Increased productivity : Saves time and effort for the driver.
3, Popular Types of Fork Positioners
Standard type : Only has the function of adjusting the lifting fork.
Side Shifting Fork Positioner : Integrated with the function of horizontal shifting, making it easier to align goods.
Heavy duty type : Suitable for lifting heavy goods or large-sized goods.
4, Installation Requirements
The forklift must have a hydraulic system with enough ports to connect.
Check the fork size to choose the right type for the fork shifter.
Install properly to ensure performance and longevity of the equipment.
Regular maintenance to keep the hydraulic system running smoothly and avoid oil leaks.
Are you looking for attachments to install fork positioner for which forklift? I can advise more about the specifications or suitable brand.
Contact: 0962722799
